| Type | MOTDR-100 |
| Wavelength Range | 1310/1550nm |
| Dynamic Range | 26/24dB |
| Event Blind Zone | 1.5m |
| ATT Blind Zone | 8m |
| Test Range | 1m – 260km |
| Pulse Width | 1ns – 20us |
| Range Accuracy | ± 0.75m |
| Loss Accuracy | 0.001dB |
| Linearity | ± 0.03dB |
| Sample Points | ≥ 160k |
| Sample Resolution | 0.015m – 16m |
| File Format | SOR Standard File Format |
| Loss Analysis | 4-point method / 5-point method |
| Laser Safety Level | Class II |
| Connector | FC/UPC (Can Change to SC, ST, LC) |
| OPM Wavelength Range | 850nm ~ 1650nm |
| OPM Interface Type | Universal Joint FC/SC/ST |
| OPM Test Range | -50dBm ~ +26dBm |
| OPM Uncertainty | 5% |
| OPM Frequency Identification | CW/270/330/1K/2kHz |
| OPM Calibration Wavelength | 850nm ~ 1650nm |
| Light Source Wavelength | 1310nm/1550nm |
| Light Source Output Power | ≥-5dBm |
| Light Source Modulation Frequency | CW 270/330/1k/2kHz |
| Light Source Connector | FC/UPC (Interchangable SC, ST) |
| VFL Wavelength | 650nm |
| VFL Output Power | ≥10mW |
| VFL Mode | CW/1Hz/2Hz |
| VFL Connector | FC/SC/ST |
| RJ45 Test Range | 300m |
| Display | Toughened glass, 3.5" Color LCD |
| Data Interface | Type-C, RJ45 x2 |
| Data Storage | Storage 8GB File Format SOR |
| Power Supply | Type-C |
| Battery Life | 5000mAh |
| Size | 173mm x 109mm x 45mm |
| Weight | 500g |
